DEEPCOOL PL650D ATX 3.1 80 PLUS BRONZE SMPS (BLACK)
The PL650D updates DeepCool non-modular PSUs with a 12V-2x6 cable and brings them into compliance with INTEL's ATX3.1 standard. These units are 80 PLUS Bronze-verified, come with a 120mm hydro-bearing fan, and will provide stable power for years to come.
NATIVE ATX3.1
Based on INTEL's latest ATX3.1 standard, the PL650D has the ability to provide twice the total system power for 0.1 ms, so power spikes will never be an issue. A native PCIe 5.1 power connector is included and has been rated up to 300 watts.
PREMIUM ELECTROLYTIC CAPACITORS
High-grade electrolytic capacitors allow the PL-D series of PSUs to keep the hold-up time to ≥ 16 ms under full load (100%), and they can easily handle power outages.
| Model Number |
DEEPCOOL PL650D ATX 3.1 80 PLUS BRONZE SMPS (BLACK) |
| Type |
ATX12V V3.1 |
| Product Dimensions |
150×140×86mm (W x L x H) |
| Efficiency certification |
80Plus Bronze/Cybenetics Silver/PPLP Silver/CQC II 级 |
| Fan Size |
120mm |
| Fan Bearing |
HYB(Hydro Bearing) |
| Topology |
Active PFC+DC to DC |
| Capacitors |
Chinese Electrolytic Capacitors |
| Power Good Signal |
100-150ms |
| Hold Up Time |
≥16ms |
| Efficiency |
≥85% Under Typical Load(50% Loading) |
| Protection |
OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
| Operation Temperature |
0 - 40℃ |
| Regulatory |
CE/FCC/CCC/RCM/EAC/BIS/
CAN ICES-003(B)/NMB-003(B) /TUV-RH |
| Erp Regulation |
ErP 2014 |
| Environment Protection |
WEEE/中国 RoHS/Triman/P65 |
| MTBF |
100,000 Hours |
| EAN P/N |
6933412721130 R-PL650D-FC0B-CN-V2
6933412721147 R-PL650D-FC0B-AU-V2
6933412721154 R-PL650D-FC0B-EU-V2
6933412721161 R-PL650D-FC0B-JP-V2
6933412721178 R-PL650D-FC0B-UK-V2
6933412721185 R-PL650D-FC0B-US-V2
6933412721192 R-PL650D-FC0B-IN-V2
6933412721208 R-PL650D-FC0B-WO-V2
6933412721215 R-PL650D-FC0B-BP-V2 |
