Description
DEEPCOOL PN1200M ATX 3.1 80 PLUS GOLD SMPS (BLACK)
FUTURE PROOF
With the ability to provide twice the total system power for 0.1 ms, random power spikes will never be an issue. The PN1200M will provide stable and consistent power for legacy and next-generation PCs for the foreseeable future.
POWER YOU CAN TRUST
Through the use of a main Japanese electrolytic capacitor, active PFC, half-bridge SRC LLC, and a DC-to-DC topology, the PN1200M can keep the hold-up time to ≥ 16 ms under a high load of 80%.
PCI-E 5.1 POWER
Equipped with a high-grade 105C-resistant 16AWG copper-core 12V-2x6 cable, the PN1200M provides up to 600W for modern GPUs.
| Model Number |
DEEPCOOL PN1200M ATX 3.1 80 PLUS GOLD SMPS (BLACK) |
| Type |
ATX12V V3.1 |
| Product Dimensions |
150×150×86mm (W x L x H) |
| Efficiency certification |
80Plus Gold |
| Fan Size |
135mm |
| Fan Bearing |
FDB (Fluid Dynamic Bearing) |
| Topology |
Active PFC + Half Bridge SRC LLC + DC to DC |
| Capacitors |
Japanese Bulk Capacitor |
| Power Good Signal |
100-150ms |
| Hold Up Time |
≥16ms(80% Load) |
| Efficiency |
≥90% Under Typical Load(50% Loading) |
| Protection |
OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
| Operation Temperature |
0 - 40℃ |
| Regulatory |
CE/FCC/CCC/TUV-RH/cTUVus/RCM/EAC/BIS |
| Erp Regulation |
ErP 2014 |
| Environment Protection |
WEEE/中国 RoHS/Triman/P65 |
| MTBF |
100,000 Hours |
